SPC-3150 15″ Intel Celeron Processor Resistive Touch Stainless Steel Panel PC
● Intel Celeron Processor
● 15″ industrial LCD panel and touch
● M12 I/O Connectors
● Food-grade SUS304 stainless steel housing
● Fanless and IP65 Protection
● -10~50℃ Operating temperature
● Optional 9~36VDC input
● Optional WiFi, Bluetooth, 4G, 5G
SPC-3150 15″ stainless steel industrial tablet computer uses 304 food-grade stainless steel shell, which has good corrosion resistance, durability and easy to clean. The computer adopts fanless and waterproof design to meet IP66 protection level. M12 full waterproof interface can better protect internal devices. It can choose 15-19 inch multi-size display screen, which is suitable for automatic application in pharmaceutical and food processing industry.
▌Specifications
| System | CPU | Intel Quad-Core Celeron J1900 (2.0GHz) |
| Memory | 1 x SO-DIMM DDR3L-1333/1600 (up to 8GB) | |
| Storage | 1 x Full-size Mini-PCIe for mSATA SSD | |
| Operating System | Windows 7/10, Linux | |
| Display | Size | 15-inch |
| Resolution | 1024 x 768 | |
| Brightness | 300 cd/m² | |
| Contrast Ratio | 600：1 | |
| LED Lifetime | 30000 hrs | |
| Touchscreen | Type | Industrial five-wire resistive touch |
| I/O | Serial Port | 1 x RS232, 1x RS232/485 |
| USB Port | 4 x USB2.0 | |
| Ethernet | 2 x GbE LAN | |
| Power | 1 x DC-in | |
| Others | 1 x ATX Switch | |
| Expansion | Mini-PCIe | 1 x Full-size Mini-PCIe for mSATA 1 x Full-size Mini-PCIe |
| Power Specification | Power Input | DC 12V |
| Consumption | 23W(Typ.) | |
| Environment | Operating Temperature | -10~50°C |
| Storage Temperature | -20~60°C | |
| Relative Humidity | 5%-90%,@ 40°C (non-condensing) | |
| IPProtection | IP66 | |
| Certifications | CE, FCC | |
| Physical Characteristics | Material | SUS 304 |
| Mounting Mode | VESA-mount | |
| Dimension (W x L x H) | 406 x 330 x 51 mm | |
| Weight | 5.7Kg | |
| Packing List | 1 x SPC-3150 | |
| Power Adapter and Cord | ||
| Interface conversion cord | ||
| 1 x Certificate | ||
| 1 x Warranty Card | ||
