SPC-3150 15″ Intel J1900 Resistive Touch Stainless Steel Panel PC

Intel Celeron J1900 (2.0 GHz)
15″ industrial LCD panel and touch
M12 I/O Connectors
Food-grade SUS304 stainless steel housing
Fanless and IP65 Protection
-10~50℃ Wide temperature operating
Optional 9~36VDC input
Optional WiFi, Bluetooth, 4G, 5G

SPC-3150 15″ stainless steel industrial tablet computer uses 304 food-grade stainless steel shell, which has good corrosion resistance, durability and easy to clean. The computer adopts fanless and waterproof design to meet IP66 protection level. M12 full waterproof interface can better protect internal devices. It can choose 15-19 inch multi-size display screen, which is suitable for automatic application in pharmaceutical and food processing industry.

Specifications

System CPU Intel Quad-Core Celeron J1900 (2.0GHz)
Memory 1 x SO-DIMM DDR3L-1333/1600 (up to 8GB)
Storage 1 x Full-size Mini-PCIe for mSATA SSD
1 x 2.5″ driver bay for SATA3.0 HDD/SSD
Operating System Windows 7/10, Linux
Display Size 15-inch
Resolution 1024 x 768
Brightness 300 cd/m²
Contrast Ratio 600:1
LED Lifetime 30000 hrs
Touchscreen Type Industrial five-wire resistive touch
I/O Serial Port 1 x RS232,  1x RS232/485
USB Port 4 x USB2.0
Ethernet 2 x GbE LAN
Others 1 x DC-in
1 x ATX Switch
Expansion Mini-PCIe 1 x Full-size Mini-PCIe for mSATA
1 x Full-size Mini-PCIe
Power Specification Power Input DC 12V
Consumption 23W(Typ.)
Environment Operating Temperature -10~50°C
Storage Temperature -20~60°C
Relative Humidity 5%-90%,@ 40°C (non-condensing)
IPProtection IP66
Certifications CE, FCC
Physical Characteristics Material SUS 304
Mounting Mode VESA-mount
Dimension (W x L x H) 406 x 330 x 51 mm
Weight 5.7Kg
       Packing List 1 x SPC-3150
Power Adapter and Cord
External patch cord
1 x Certificate
1 x Warranty Card
