DIC-427 4U Rack Mount Chassis with ATX Large Motherboard Support and 7 Card Expansion
● Impact resistant drive bay design can support 8x 3.5″ hard drives, 2x 5.25” optical drive, 1x 3.5” floppy drive
● Visualized power and HDD status indicators to enhance system availability
● Easy to replace dustproof filter screen in front, convenient for system maintenance
● Lockable front door to prevent unauthorized access
DIC-427 is a robust 4U rack mount chassis with ATX support, 7 card slots, an impact-resistant design, and a drive bay for 8 x 3.5″ HDDs, 2 x 5.25″ optical drives, and 1 x 3.5″ floppy drive. It has visualized power and HDD status indicators, an easy-to-replace dustproof filter screen, and a lockable front door for added security.
▌Specifications
| Product Specifications | |
| Motherboard Specs | Standard ATX big motherboard |
| Drive Bay | 8x 3.5″ disk drive, 2x 5.25″optical drive, 1x 3.5″ floppy drive |
| Power Specs | Standard ATX power supply |
| Front I/O Interface | 2 x USB2.0 |
| Back I/O Interface | 2x COM, 1x LPT, 7x board expansion slot |
| Cooling | Front panel 1x 12025 fan, rear window 2x 8025 fan |
| Miscellaneous | |
| LED Indicators | Power light, hard drive light, keyboard lock indicator light |
| Control | Power switch, reset switch, keyboard lock switch |
| Certification | |
| EMC | CE, FCC Class A |
| Environment | |
| Operating Temperature | -0 to 50°C (32 to 122°F) |
| Storage Temperature | -20 to 60°C (-4 to 140°F) |
| Relative Humidity | 10% to 85% @ 40°C (104°F), non-condensing |
| Mechanical | |
| Mounting | Rackmount |
| Dimension (W x D x H) | 427 x 450 x 177mm (16.81 x 17.72 x 6.97 inches) |
| Weight | 11.3 KG (24.91 lbs) |
