DPM-1120G 12.1″ Capacitive High-brightness Industrial Monitor

12.1″LCD, capacitive touch
Compact structure, front panel IP65 dustproof and waterproof
All-metal structure design, solid and durable
Support panel and VESA installation
1000 lumen display,
Touch screen surface AG AF treatment



Darveen DPM series industrial touch display adopts high-brightness display screen, the surface of the touch screen is anti-glare and anti-fingerprint treatment, and adopts modular and all-metal structure design, which has good seismic resistance and durability, as well as excellent heat dissipation and anti-rust ability. With its stable system architecture, Daven products perform well in industrial applications. Users can choose 4:3 and 16:9 multi-scale display screens to meet various applications such as industrial automation outdoor environment.


Display size 12.1-inch
resolving power 1024 x 768
viewing angle 80/80/80/80
Color Support 16.7M
brightness 1000 cd/m²
contrast ratio 700:1
response time 3/5 (Typ.)(Tr/Td) ms
Backlight LED
Backlight life 50000h
Touchscreen Type Projection multi touch capacitive touch screen
control interface USB
Surface hardness ≥7H
Glass cover AG AF
Transmittance 80%
I/O USB 1 x USB2.0
Display 1 x VGA
1 x DVI
Others 1 x DC-IN (2-Pin Phoenix)
Power Specification Power Input DC 12~24V
Power Adapter AC-DC, 12V@5A, 60W
Power Consumption 12W(Typ.)
Environment Operating Temperature -10~50 °C
Storage Temperature -20~60 ℃
Relative Humidity 10%-90%,@ 40 °C (non-condensing)
Vibration 5~500Hz, 0.026 G ²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Certifications CE, FCC
Physical Characteristics Meterial Aluminum alloy panel, all-metal structure
Mounting Mode Panel-mount, VESA-mount
Dimension (W x L x H) 310 x 248 x 41.5 mm
Weight 2.45Kg
Packing List Packing List 1 x DPM-1120G
1 x AC-DC power adapter
1 x USB control cable
1 x VGA data cable
1 x Fixed cable buckle
1 x Certificate
1 x Warranty Card
8 x Panel Mounting Buckles
