FMT-661M 8″ Windows 11 Fleet Management Terminal with Intel® Alder Lake-N97 Processor
● 8″ TFT-LCD with projective capacitive touchscreen
● Rugged aluminum enclosure and fanless design
● Wide range 8-36VDC power input
● Flexible expansion capability for Wi-Fi,Bluetooth,LTE,5G, GNSS, and CAN2.0B
● Robust M12 I/O interface
● IP65 protection, MIL-STD-810H shock & vibration complian
FMT-661M is a brand new fleet management terminal featuring an 8-inch touchscreen, and an Intel® Alder Lake-N97 processor. It comes pre-installed with the Windows 11 operating system for fleet management applications.WiFi, LTE/5G,Bluetooth and GNSS modules can be all integrated into the FMT-661M for realtime data exchange, navigation and communication. With its 10-point capacitive touchscreen, users can enjoy user-friendly and efficient operations during their daily tasks.
▌Specifications
| Display | |
| Size | 8 inch (16:9) |
| Touch Type | Projected capacitive multi touch |
| Display Type | TFT LCD |
| Resolution | 1280 x 720 |
| Luminance | 750 nits |
| Contrast Ratio | 1000: 1 |
| View Angles | 85 (left), 85 (right), 85 (up), 85 (down) |
| Color | 16.2M |
| System | |
| CPU | Intel® Alder Lake-N97, Intel 7, 4-core, up to 3.6GHz |
| Chipset | Intel® Alder Lake-N Plaorm |
| Memory | 4GB DDR4-2666 SO-DIMM (up to 16GB) |
| Storage | 128GB M.2 2280 SSD (up to 2TB) |
| Graphics | Intel® UHD Graphics |
| BIOS | AMI UEFI BIOS |
| Keypad & Keyboard | |
| Keypad | Power on/off, Brightness adjustment, Volume adjustment, 4x Function keys, Function switch key, Power LED indicator |
| I/O Ports | |
| USB | 2x USB 2.0 (M12) |
| Serial | 2x RS-232 (M12) |
| Ethernet | 1x GbE LAN (M12) |
| SIM Card Slot | 1x SIM card slot, 2x SIM card slot (optional) |
| CAN bus | 2x CAN2.0B (M12, optional) |
| Antenna | 4x SMA connectors for Wi-Fi, Bluetooth, 4G, GPS (optional) 7x SMA connectors for Wi-Fi, Bluetooth, 5G, GPS (optional) 2x TNC connectors for RTK (optional) |
| RF Communication | |
| Wi-Fi | Wi-Fi 6E: 802.11a/b/g/n/ac/ax, 2.4G/5G/6G (optional) Wi-Fi 7: 802.11a/b/g/n/ac/ax/be, 2.4G/5G/6G (optional) |
| Cellular | 4G, LTE (optional), 5G, NSA/SA (optional) |
| Bluetooth | Bluetooth 5.3 (depends on Wi-Fi 6E, optional), Bluetooth 5.4 (depends on Wi-Fi 7, optional) |
| GNSS | GPS, GLONASS, Galileo, BeiDou (optional) |
| Audio | |
| Speaker | 8Ω/1W, dual studio speakers |
| Power | |
| DC Input | 8 to 36VDC |
| Power Consumption | 18W (Typ.) |
| Power Mode | ATX (default), AT |
| Operating System | |
| Windows | Windows 11 IoT Enterprise LTSC, Windows 11 Pro |
| Mechanical | |
| Dimensions (W x D x H) | 235 x 168 x 49.5 mm (9.25 x 6.61 x 1.95 inches) |
| Weight (N.W.) | 1.55 kg (3.42 lbs) |
| Mounting Mode | VESA 75 |
| Material | Die-casting Aluminum with Heavy Duty Metal |
| Environment | |
| Operating Temperature | -30 to 60℃ (-22 to 140°F) |
| Storage Temperature | -40 to 70℃ (-40 to 158°F) |
| Relative Humidity | 95% @ 70°C (158°F), non-condensing |
| Shock | MIL-STD-810H Method 514.8 Procedure I |
| Vibration | MIL-STD-810H Method 516.8 Procedure I |
| IP Rating | IP65 compliant |
| Certification | |
| EMC | CE, FCC |
