RPC-5150 15″ Fully Protected Panel PC with 6th Gen Intel® Core™ i5 Processor
●Intel® Core™ i5-6200U processor
●15″ panel PC with capacitive or resistive touch screen
●Sealed to full IP65 protection against water and dust
●M12 connectors for maximum protection against vibration, shock and dirt
● -10 to 50℃ operating temperature
The RPC-5150 is a 15″ industrial-grade touch panel PC powered by a high-performance Intel® Core™ i5 processor, ideally suited for use in industrial HMI applications. With its modular, fanless, and shockproof design, the robust RPC-5150 is fully IP65 rated for dustproof and waterproof protection, ensuring extreme durability. The RPC series offers display screen options available in both 4:3 and 16:9 aspect ratios. Moreover, it comes equipped with M12 I/O connectors, empowering it to withstand even the harshest environments.
▌Specifications
| Display | ||
| Size | 15 inch | |
| Touch Type | 5-wire resistive touch/projected capacitive multi touch (optional) | |
| Resolution | 1024 x 768 | |
| Luminance | 450 nits | |
| Contrast Ratio | 700:1 | |
| View Angles | 80 (left), 80 (right), 80 (up), 80 (down) | |
| Color | 16.7 M | |
| System | ||
| CPU | Intel® Core™ i5-6200U processor | |
| Memory | DDR3L up to 16GB | |
| Storage | mSATA up to 1TB | |
| Graphics | Intel® HD graphics 520 | |
| BIOS | AMI | |
| I/O Ports | ||
| USB | 2x USB2.0 | |
| Serial | 2x COM (supports 2x RS232 or 1x RS232 and 1x RS485) | |
| Ethernet | 2x GbE LAN | |
| Expansion Slot | ||
| Mini PCIe | 1x Full length Mini PCIe for mSATA, 1x Full length Mini PCIe for Wi-Fi or 4G | |
| Antenna | 2x SMA antenna holes | |
| RF Communication | ||
| Wi-Fi | Wi-Fi 802.11 a/b/g/n/ac (optional) | |
| Cellular | 4G/LTE (optional) | |
| Bluetooth | BT4.0 (optional) | |
| Power | ||
| Button | Power on/off | |
| DC Input | 12 VDC | |
| Power Consumption | 25 W (Typ.) | |
| Power Mode | ATX | |
| Operating System | ||
| Windows | Windows 7, Windows 10 | |
| Mechanical | ||
| Dimensions (W x D x H) | 366.5 x 290.5 x 64 mm (14.43 x 11.44 x 2.52 inches) | |
| Weight (N.W.) | 5.4 kg (11.91 lbs) | |
| Mounting | VESA 100 | |
| Material | Aluminum and SGCC | |
| Environment | ||
| Operating Temperature | -10 to 50℃ (14 to 122°F) | |
| Storage Temperature | -40 to 80℃ (-40 to 176°F) | |
| Relative Humidity | 10% to 95% @ 40°C (104°F), non-condensing | |
| IP Rating | IP65 compliant | |
