APC-9100 10.1″RK3399 Capacitive touch Android Panel PC

10.1″ LED Backlight LCD and P-cap Multi-Touch Panel
Front Panel IP65
Rockchip RK3399,ARM 2xCortex-A72+4xCortex-A53 1.8GHZ
Panel and Vesa Mounting

APC-9100 10.1″ industrial tablet computer adopts full plane capacitive multi-point touch screen, modular, fanless and shockproof design. 4:3 and 16:9 multi size range touch screen can be selected to meet various industrial applications. APC-9100 Android industrial tablet computer adopts low-power processor, with its stable system architecture, it has excellent performance in industrial applications. In addition, the whole series of products are made of aluminum alloy front panel and the machine body make for metal material, with excellent heat dissipation and rust resistance.


System CPU Rockchip RK3399,ARM 2xCortex-A72+4xCortex-A53 1.8GHZ
Memory DDR3 4GB
Storage EMMC 16G/32G
Operating System Android 10
Display Size 10.1-inch
Resolution 1280 ×800
Viewing Angle 85/85/85/85
Color Support 16.7M
Brightness 350 cd/m²
Contrast Ratio 800:1
Response Time 2/5 (Typ.)(Tr/Td) ms
Backlight LED
LED Lifetime 25000 hrs
Touch Screen Type Projection multi touch capacitive touch screen
 control interface USB
Surface hardness ≥6H
Transmittance 85%
I/O Serial Port 1 x RS-232
USB Port 4 x USB3.0
Ethernet 2 x GbE LAN
GPIO 1 x GPIO (Optional)
Others 1 x DC-IN (3-Pin Phoenix)
1 x Remote Switch Connector
1 x ATX  Power Switch
Audio Audio 1 x Line-out 1 x Line-in
Speaker 2 x Speaker (Optional)
Power Power Input 9~36V
Power Adapter AC-DC, 12V@5A, 60W
Power Consumption 9W(Typ.)
Environment Operating Temperature -10~50°C
Storage Temperature -20~60°C
Relative Humidity 10%-90%,@ 40 °C (non-condensing)
Vibration 5~500Hz, 0.026 G ²/Hz, 2.16 Grms, X,Y, Z, 1 hour per axis
Certifications CE, FCC
Physical Characteristics Meterial Aluminum alloy panel, all-metal structure
Mounting Mode Panel-mount, VESA-mount
Dimension (W x L x H) 261.4 x 174.6 x 34 mm
Weight 1.8Kg
